6. Repeat steps 4 and 5 to remove the second optical drive (if available).
Related Links
Installing the Optical Drive
Installing The Optical Drive
1. Slide up the optical-drive latch and push the optical drive from the front towards the back of the computer.
2. Connect the data cable and power cable to the optical drive.
3. Install the front bezel.
4. Install the cover.
5. Follow the procedures in After Working Inside Your Computer.
Related Links
Removing the Optical Drive
Removing the Hard Drive
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the cover.
3. Remove the data cable and power cable from the back of the hard drive.
4. Press both blue securing-bracket tabs inwards and lift the hard-drive bracket out of the bay.
13
