Removing the Heat Sink and Processor
Removing The Coin-Cell Battery
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the cover.
3. Press the release latch away from the coin-cell battery to allow the battery to pop-up from the socket.
4. Lift the coin-cell battery out of the computer.
Related Links
Installing The Coin-Cell Battery
Installing The Coin-Cell Battery
1. Place the coin-cell battery into its slot on the system board.
2. Press the coin-cell battery downwards until it is secured.
3. Install the cover.
4. Follow the procedures in After Working Inside Your Computer.
Related Links
Removing the Coin-Cell Battery
Removing the Power-Switch Cable
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the cover.
3. Remove the front bezel.
4. Remove the optical drive.
20
