Removing and installing components
NOTE: The images in this document may differ from your computer depending on the configuration you ordered.
Topics:
• Disassembly and reassembly
Disassembly and reassembly
Side cover
Removing side cover
1. Follow the procedure in Before working inside your computer.
2. To remove the cover:
a. Loosen the captive screws that secure the cover to the computer [1].
b. Slide the cover towards the back of the system and lift it from the system [2].
4
Removing and installing components 17
