Dell OptiPlex 3070 Tower - M.2 Pcie SSD

2. Install the:
a. Front bezel
b. Side cover
3. Follow the procedure in After working inside your computer.
M.2 PCIe SSD
Removing M.2 SSD
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. Side cover
b. Front bezel
3. Open the front panel door.
4. To remove the M.2 SSD:
a. Remove the single screw that secures the SSD to the system board [1].
b. Slide the M.2 SSD from the connector on the system board [2].
Removing and installing components
33
