Dell OptiPlex 3070 Tower - Page 19

Installing front bezel
1. To install the front bezel:
a. Position the bezel to align the tab holders with the slots on the system chassis [1].
b. Press the bezel until the tabs click into place [2].
Removing and installing components
19
