Dell OptiPlex 5000 Small Form Factor User Manual

Table 1. Screw list (continued)
Component Screw type Quantity Screw image
System board #6-32 5
Customer Replaceable Units (CRU) and Field
Replaceable Units (FRU) list
Table 2. CRU/FRU list
OptiPlex 5000 Small Form Factor CRU component FRU component
Side cover
Front bezel
Intrusion switch
2.5-inch hard drive
3.5-inch hard drive
Optical drive
Hard-drive and optical-drive bracket
Supporting bracket
M.2 Solid-state drive
WLAN card
Memory module
Expansion card
Heat-sink and fan assembly
Removing and installing components 11
