Table 7. Memory matrix(continued)
Configuration Slot
32 GB DDR4 32 GB
32 GB DDR4 16 GB 16 GB
64 GB DDR4 32 GB 32 GB
External ports
The following table lists the external ports of your OptiPlex Micro 7010.
Table 8. External ports
Description Values
Network port
One RJ45 Ethernet port 10/100/1000 Mbps
USB ports
● Two USB 3.2 Gen 1 ports (Front)
● Two USB 3.2 Gen 1 ports (Rear)
● One USB 2.0 port (Rear)
● One USB 2.0 port with Smart Power On (Rear)
Audio port
One universal audio jack (Front)
Video port
● One optional video port (HDMI 2.1/Displayport 1.4a
(HBR3)/VGA/PS2/serial/USB Type-C with DisplayPort
Alt mode + power delivery in) (Rear)
NOTE: You may connect a 90 W Dell USB-C
hub monitor to the optional Type-C port as a
consolidated power, display and USB I/O solution for
your computer.
● One DisplayPort 1.4a (HBR2) (Rear)
● One HDMI 1.4b
Media-card reader
Not supported
Power-adapter port
● One DC-in port with 4.50 mm barrel
● One Type-C power in (optional)
NOTE: You may connect a 90 W Dell USB-C hub monitor
to the optional Type-C port as a consolidated power,
display and I/O solution for your computer.
Security-cable slot
● One Kensington lock slot
● One padlock ring
Internal slots
The following table lists the internal slots of your OptiPlex Micro 7010.
Table 9. Internal slots
Description Values
M.2
● One M.2 2230 slot for WiFi and Bluetooth card
● One M.2 2230/2280 slot for SSD
Specifications of OptiPlex Micro 7010 17
