3. Follow the procedure in After working inside your computer.
Removing SMA antenna assembly
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the side cover.
3. Remove the hard drive, if applicable.
4. Remove the wireless card.
About this task
The following images indicate the location of SMA antenna assembly and provide a visual representation of the removal
procedure.
NOTE: To upgrade to SMA antenna, the internal antenna (white cable) needs to be removed.
Removing and installing Field Replaceable Units (FRUs) 77
