Power adapter
The following table lists the power adapter specifications of your OptiPlex Micro 7010.
Table 15. Power adapter specifications
Description Option one Option two
Type
65 W 90 W
Connector dimensions:
External diameter
4.50 mm 4.50 mm
Internal diameter
2.90 mm 2.90 mm
Power-adapter dimensions:
Height
28 mm (1.10 in.) 32 mm (1.26 in.)
Width
47 mm (1.85 in.) 52 mm (2.05 in.)
Depth
108 mm (4.25 in.) 128 mm (5.04 in.)
Input voltage
100 VAC x 240 VAC 100 VAC x 240 VAC
Input frequency
50 Hz x 60 Hz 50 Hz x 60 Hz
Input current (maximum)
1.60 A / 1.70 A 1.50 A
Output current (continuous)
3.34 A 4.62 A
Rated output voltage
19.50 VDC 19.50 VDC
Temperature range:
Operating
0°C to 40°C (32°F to 104°F) 0°C to 40°C (32°F to 104°F)
Storage
-40°C to 70°C (-40°F to 158°F) -40°C to 70°C (-40°F to 158°F)
CAUTION: Operating and storage temperature ranges may differ among components, so operating or storing
the device outside these ranges may impact the performance of specific components.
GPU—Integrated
The following table lists the specifications of the integrated Graphics Processing Unit (GPU) supported by your OptiPlex Micro
7010.
Table 16. GPU—Integrated
Controller External display support Memory size Processor
Intel UHD Graphics 710
● One DisplayPort 1.4a HBR2
● One HDMI 1.4b
Shared system memory Intel Celeron G6900T and
Intel Pentium Gold G7400T
processors
Intel UHD Graphics 730
● One DisplayPort 1.4a HBR2
● One HDMI 1.4b
Shared system memory 13
th
Generation Intel Core
i5-13400T and i3-13100T
processors
20 Specifications of OptiPlex Micro 7010
