Removing the speakers
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
1. Remove the base cover.
2. Remove the battery.
Procedure
1. Peel the tape that secures the speaker cable to the connector.
2. Disconnect the speaker cable from the system board.
3. Peel off the tapes and release the speaker cable from the routing guides on the palm-rest assembly.
4. Remove the speaker cable from the routing guides on the palm-rest assembly.
5. Lift the speakers off the palm-rest assembly.
24
Removing the speakers 45
