Dell P2314T User Manual

10 About Your Monitor
Touch
P2314T P2714T
Type Projected Capacitive System
Panel Diagonal 23.1 inch 27.1 inch
Panel Thickness 2.4 mm 3.1 mm
Active Area Extended beyond Viewing Area
Sensor Stack thickness 0.5 mm
Cover Glass Thickness
1.1 mm 1.8 mm
Input Method Bare finger, thin gloves, conductive stylus
Touch point 10 touch-points
Response time <10 ms
Output position resolution 32767 x 32767
Touch method Fingers and thin gloves
Operating system Windows 8/Windows 8.1 certified
Resolution
Horizontal scan range 30 kHz – 83 kHz (automatic)
Vertical scan range 56 Hz – 75 Hz (automatic)
Maximum resolution 1920X1080 at 60 Hz
Supported video modes 480p, 576p, 720p, 1080p, and 1080i
Electrical
Video input signals DisplayPort 1.2/HDMI/MHL 2.0/VGA
Synchronization input
signals
•Separate horizontal and vertical synchronization.
•Polarity-free TTL level
•SOG (composite SYNC on green)
AC/DC adapter input:
Voltage 100 VAC–240 VAC
Frequency 50 Hz/60 Hz + 3 Hz
Current 1.5 A (maximum)
For use only with power supply DELL DA65NM111-00.
Inrush current 150 A at 115/230 VAC
Input voltage 19.5 VDC, 3.34 A

Dell P2314T Specifications

General

Pixel pitch	0.265 x 0.265 mm
Screen shape	Flat
LED backlight	Yes
Response time	8 ms
Display diagonal	23 \
Touchscreen type	Tabletop
Display brightness	270 cd/m²
Display technology	LED
Contrast ratio (dynamic)	8000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display diagonal (metric)	58.4 cm
Certification	EPEAT Gold
Product color	Black, Silver
Glass thickness	1.1 mm
Display viewable area (HxV)	286.42 x 509.18 mm
Dimensions (W x D x H) with stand	569.9 x 80.9 x 412.7 mm
Cables included	HDMI, USB
Tilt angle range	-30 - 30 °
Height adjustment	216.40 - 412.70
AC input voltage	100 - 240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	17 W
USB hub version	3.2 Gen 1 (3.1 Gen 1)
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	4
Package weight	8980 g
Sustainability certificates	ENERGY STAR
NVIDIA G-SYNC	No

Weight and Dimensions

Depth (with stand)	80.9 mm
Width (with stand)	569.9 mm
Height (with stand)	412.7 mm
Weight (with stand)	7100 g
Depth (without stand)	42.2 mm
Height (without stand)	348.1 mm
Weight (without stand)	4820 g
