14 About Your Monitor
The OSD only function in the normal operation mode. If you press any button in
Active-off mode, the following message is displayed:
Pin Assignments
VGA
Pin number 15-pin side of
thecable
Pin number 15-pin side of
thecable
1 Video-Red 9 Computer 5 V/3.3 V
2 Video-Green 10 GND-sync
3 Video-Blue 11 GND
4 GND 12 DDC data
5 Self-test 13 H-sync
6 GND-R 14 V-sync
7 GND-G 15 DDC clock
8 GND-B
