Dell P2314T User Manual

About Your Monitor 9
Specifications
Panel
P2314T P2714T
Screen type Active matrix - TFT LCD
Panel type In-Plane Switching / Plane
to Line Switching
Plane to Line Switching
Viewable image:
Diagonal 58.42 cm (23 inches) 68.58 cm (27inches)
Horizontal (active area) 509.18 mm (20.05 inches) 597.89 mm (23.54inches)
Vertical (active area) 286.42 mm (11.28 inches) 336.31 mm (13.24inches)
Area 145839.34 mm
2
(226.05inch
2
)
201076.39 mm
2
(311.67inch
2
)
Pixel pitch 0.265 mm 0.311 mm
Viewing angle:
Horizontal 178 degrees typical
Vertical 178 degrees typical
Luminance:
Panel 300 cd/m² (typical)
Monitor 270 cd/m² (typical)
Contrast ratio 1000:1 (typical)
Dynamic contrast ratio 8,000,000:1 (typical)
Faceplate coating Antiglare with hard-coating 3H
Glass gloss >30 gloss units.
NOTE: For displays with edge-to-edge design, consider
the placement of the display as the reflection of
surrounding light and bright surfaces from the glass may
cause disturbances.
Backlight LED edgelight system
Response Time 8 ms gray-to-gray (typical) 8 ms gray-to-gray (typical)
Color depth 16.77 million colors
Color gamut (Typical) 83% (CIE1976)
NOTE: Color gamut (typical) is based on CIE1976 (83%) and
CIE1931 (72%) test standards.

Dell P2314T Specifications

General

Pixel pitch	0.265 x 0.265 mm
Screen shape	Flat
LED backlight	Yes
Response time	8 ms
Display diagonal	23 \
Touchscreen type	Tabletop
Display brightness	270 cd/m²
Display technology	LED
Contrast ratio (dynamic)	8000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display diagonal (metric)	58.4 cm
Certification	EPEAT Gold
Product color	Black, Silver
Glass thickness	1.1 mm
Display viewable area (HxV)	286.42 x 509.18 mm
Dimensions (W x D x H) with stand	569.9 x 80.9 x 412.7 mm
Cables included	HDMI, USB
Tilt angle range	-30 - 30 °
Height adjustment	216.40 - 412.70
AC input voltage	100 - 240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	17 W
USB hub version	3.2 Gen 1 (3.1 Gen 1)
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	4
Package weight	8980 g
Sustainability certificates	ENERGY STAR
NVIDIA G-SYNC	No

Weight and Dimensions

Depth (with stand)	80.9 mm
Width (with stand)	569.9 mm
Height (with stand)	412.7 mm
Weight (with stand)	7100 g
Depth (without stand)	42.2 mm
Height (without stand)	348.1 mm
Weight (without stand)	4820 g
