Dell P2314T - Parts and Controls Overview

About Your Monitor 7
Parts and Controls
Front view Side-panel controls
Label Description
1 Function buttons (For more information, see Operating the Monitor)
2 Power On/Off button (with indicator light)
Back View
Label Description Use
1 100mmx100mm VESA mounting
holes (under VESA cover)
Wall mount monitor using
100mmx100mm VESA‑compatible
wall‑mount kit.
2 Regulatory label Lists the regulatory approvals.
3 Service Tag label (P2714T only) Refer to this label if you need to contact
Dell for technical support.
4 Barcode serial number label Refer to this label if you need to contact
Dell for technical support.
5 Cable‑management slot Use to organize cables by placing them
through the slot.
2
1
1
2
43
5
