24 Operating the Monitor
OSD Options
Menu and Submenus Description
Energy Use
This meter shows, in real time, the energy level being
consumed by the monitor.
Brightness/Contrast
Use this menu to activate Brightness/Contrast adjustment.
Brightness
Brightness adjusts the luminance of the backlight
(minimum 0; maximum 100).
Press the button to increase brightness.
Press the button to decrease brightness.
NOTE: Brightness control is disabled during “Screen dim” in
PowerNap option when screen saver is activated.
Contrast
Press the button to increase contrast and Press the
button to decrease contrast (between 0 and 100).
Adjust Brightness first, and then adjust Contrast only if
further adjustment is necessary.
Contrast adjusts the difference between darkness and
lightness on the monitor.
To Next Page
