Dell P2314T - Bottom View

8 About Your Monitor
Bottom View
Label Description Use
1 Power‑cable connector Connect the power cable.
2 DisplayPort connector Connect the DisplayPort cable.
3 HDMI (MHL) 1 port Connect your computer with HDMI cable or
portable device with MHL cable (optional).
4 HDMI (MHL) 2 port Connect your computer with HDMI cable or
portable device with MHL cable (optional).
5 VGA port To connect your computer to the monitor using a
VGA cable (optional).
6 Audio line‑out port Connect speakers to playback audio coming
through HDMI or DisplayPort audio channels.
Only supports 2‑channel audio.
NOTE: The audio line-out port does not support
headphones.
7 USB upstream port Connect the USB cable from the monitor to the
computer to allow you to use the USB ports and
touch screen function on the monitor.
8 USB 2.0 downstream
ports
Connect your USB device.
You can only use this port after you connect
the USB cable from your computer to the USB
upstream port on the monitor.
9 Security‑cable slot Use a security cable to prevent unauthorized
movement of your monitor.
10 USB 3.0 downstream
ports
Connect your USB device.
You can only use this port after you connect
the USB cable from your computer to the USB
upstream port on the monitor.
1
2 5 6
7
9
10
3
8
4
