About your monitor │ 11
Back view
Back view with monitor stand
Label Description Use
1 VESA mounting holes (100 mm
x 1
00 mm - behind attached
VES
A Cover)
Wall-mount the monitor using VESA-
c
ompatible wall mount kit (100 mm x
10
0 mm).
2 Regulatory label Lists the regulatory approvals.
3 Stand release button Releases stand from the monitor.
4 Barcode, serial number, and
Service
Tag label
Refer to this label if you need to
contact Dell for technical support.
5 Power On/Off button To turn the monitor on or off.
6 Joystick Use to control the OSD menu. For
mo
re Information, see Operating the
monitor.
7 Cable-management slot Use to organize cables by inserting
them
through the slot. But this does
not accommodate DVI cable.
