26 │ About your monitor
USB 3.2 Gen1 (5 Gbps) downstream connector
Pin number 9-pin side of the connector
1 VCC
2 D-
3 D+
4 GND
5 SSRX-
6 SSRX+
7 GND
8 SSTX-
9 SSTX+
USB ports
• 1 USB Type-B upstream - rear
• 2 USB Type-A downstream - rear
• 2 USB Type-A downstream - bottom
NOTE: USB 3.2 Gen1 (5 Gbps) functionality requires a USB 3.2 Gen1-
capable computer.
NOTE: The USB ports on the monitor work only when the monitor is
turned On or in Standby mode. If you turn Off the monitor and then
turn it On, the attached peripherals may take a few seconds to resume
normal functionality.
