Installing the keyboard
1 Press and align the keyboard to its compartment.
2 Replace the screws to secure the keyboard to the computer.
3 Slide the keyboard trim and align it to its position on the computer. Ensure that the keyboard trim clicks into its place
4 Connect the keyboard data cables to the system board.
NOTE: Ensure that you fold the keyboard data cable in perfect alignment.
5 Ax the tape on the keyboard data cables.
6 Install the:
a hard drive
b battery
c battery cover
7 Follow the procedure in After working inside your computer.
Base cover
Removing the base cover
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a battery cover
b battery
3 To remove base cover:
a Remove the M2.5X5.0 screws that secure the base cover to the computer [1].
b Slide and lift the base cover away from the computer [2].
