— 34 —
P792
NOTE: The components identifi ed by shading
and ! mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es par un trame et une
marque ! sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES
D924 8-719-069-55 DIODE UDZSTE-175.6B
D928 8-719-067-40 DIODE AZ23C6V2
D929 8-719-067-40 DIODE AZ23C6V2
D930 8-719-067-40 DIODE AZ23C6V2
D931 8-719-067-40 DIODE AZ23C6V2
D936 8-719-069-55 DIODE UDZSTE-175.6B
D937 8-719-069-55 DIODE UDZSTE-175.6B
D943 8-719-801-78 DIODE MA151WK-TX
FUSE
! F601 1-576-232-11 FUSE (H.B.C.) 5A/250V
FERRITE BEAD
FB502 1-412-911-11 FERRITE 0µH
FB503 1-412-911-11 FERRITE 0µH
FB504 1-412-911-11 FERRITE 0µH
FB506 1-412-911-11 FERRITE 0µH
FB507 1-412-911-11 FERRITE 0µH
FB508 1-412-911-11 FERRITE 0µH
FB601 1-412-911-11 FERRITE 0µH
FB904 1-543-961-22 FERRITE 0µH
FUSE HOLDER
FH1 1-533-223-11 CLIP, FUSE
FH2 1-533-223-11 CLIP, FUSE
IC
IC401 8-759-593-28 IC LA78040
! IC501 8-759-570-29 IC UPC6757CS
IC502 8-759-803-42 IC LA6500P-FA
! IC601 8-759-594-75 IC TEA1504/N2
IC602 8-759-592-79 IC BA00AST-V5
! IC603 8-749-016-35 IC TLP621D4-Y-LF2T
IC604 8-759-586-17 IC SPX431LAN-TR
! IC605 8-759-637-83 IC PQ12RD8S
! IC607 8-759-450-47 IC BA05T
IC608 8-759-231-53 IC L7805CV
IC701 8-759-595-52 IC CXA8070AP
IC702 8-749-018-54 IC STK391-120
IC703 8-759-822-38 IC LA6510
! IC901 6-800-150-01 IC CXD9163P/ABO
IC902 8-759-594-40 IC CXA8071CP
IC904 8-759-352-91 IC PST9143NL
IC905 8-759-640-41 IC BR24C08F-E2
IC906 8-759-640-41 IC BR24C08F-E2
IC908 8-759-491-32 IC TC74HCT04AF(EL)
CHIP CONDUCTOR
JR001 1-216-295-91 SHORT
JR002 1-216-296-11 SHORT
JR003 1-216-296-11 SHORT
JR006 1-216-296-11 SHORT
JR007 1-216-295-91 SHORT
JR008 1-216-295-91 SHORT
JR009 1-216-295-91 SHORT
JR010 1-216-296-11 SHORT
JR011 1-216-296-11 SHORT
JR012 1-216-296-11 SHORT
JR013 1-216-296-11 SHORT
JR014 1-216-296-11 SHORT
JR021 1-216-296-11 SHORT
JR022 1-216-296-11 SHORT
JR028 1-216-295-91 SHORT
JR031 1-216-296-11 SHORT
JR047 1-216-296-11 SHORT
COIL
! L501 1-406-663-21 INDUCTOR 47µH
! L502 1-406-663-21 INDUCTOR 47µH
L503 1-419-862-11 INDUCTOR 5µH
L505 1-412-552-11 INDUCTOR 2.2mH
L506 1-412-552-11 INDUCTOR 2.2mH
L508 1-424-693-11 COIL, HORIZONTAL LINEARITY
L510 1-419-863-11 COIL, HORIZONTAL CENTER
L602 1-400-054-21 INDUCTOR 22µH
L604 1-406-665-11 INDUCTOR 100µH
L606 1-406-665-11 INDUCTOR 100µH
L901 1-414-857-11 INDUCTOR 100µH
L902 1-414-857-11 INDUCTOR 100µH
FILTER
! LF602 1-429-180-11 TRANSFORMER, LINE FILTER
TRANSISTOR
Q501 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q502 8-729-026-49 TRANSISTOR 2SA1037AK-T146-QR
! Q503 8-729-035-54 TRANSISTOR 2SJ449(1)
Q504 8-729-031-89 TRANSISTOR 2SC3941A-QR(TA)
Q505 8-729-026-49 TRANSISTOR 2SA1037AK-T146-QR
Q507 8-729-055-02 TRANSISTOR 2SC5681-CA
Q508 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
! Q510 8-729-046-60 TRANSISTOR STP4NB80FP(025Y)
Q511 8-729-043-53 TRANSISTOR STD5NE10-1
Q512 8-729-043-41 TRANSISTOR 2SK2098-01MR-F119
Q513 8-729-043-41 TRANSISTOR 2SK2098-01MR-F119
Q514 8-729-043-41 TRANSISTOR 2SK2098-01MR-F119
Q515 8-729-047-72 TRANSISTOR 2SK3332
Q516 8-729-047-72 TRANSISTOR 2SK3332
Q519 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
Q520 8-729-035-54 TRANSISTOR 2SJ449(1)
Q521 8-729-026-49 TRANSISTOR 2SA1037AK-T146-QR
Q522 8-729-027-23 TRANSISTOR DTA114EKA-T146
D
