— 35 —
P792
NOTE: The components identifi ed by shading
and ! mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es par un trame et une
marque ! sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES
Q524 8-729-026-49 TRANSISTOR 2SA1037AK-T146-QR
Q525 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q601 8-729-029-92 TRANSISTOR DTC143ESA-TP
! Q602 8-729-048-61 TRANSISTOR 2SK2843LBS2SONY
Q603 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q604 8-729-119-78 TRANSISTOR 2SC3311A-RTA
Q605 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q612 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
Q901 8-729-026-49 TRANSISTOR 2SA1037AK-T146-QR
Q903 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
RESISTOR
R401 1-249-383-11 CARBON 1.5 5% 1/4W
R402 1-215-866-11 METAL OXIDE 330 5% 1W
R403 1-214-661-21 METAL 1.5 1% 1/4W
R404 1-216-669-11 METAL CHIP 5.6K 0.50% 1/10W
R405 1-214-661-21 METAL 1.5 1% 1/4W
R406 1-216-677-11 METAL CHIP 12K 0.50% 1/10W
R407 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R408 1-216-073-91 RES-CHIP 10K 5% 1/10W
R409 1-216-669-11 METAL CHIP 5.6K 0.50% 1/10W
R410 1-216-677-11 METAL CHIP 12K 0.50% 1/10W
R413 1-216-369-00 METAL OXIDE 1 5% 2W
R501 1-247-807-31 CARBON 100 5% 1/4W
R502 1-218-759-11 METAL CHIP 200K 0.50% 1/10W
R503 1-216-675-91 METAL CHIP 10K 0.50% 1/10W
R504 1-249-377-11 CARBON 0.47 5% 1/4W
R505 1-216-073-91 RES-CHIP 10K 5% 1/10W
R506 1-215-481-00 METAL 330K 1% 1/4W
R507 1-215-431-00 METAL 2.7K 1% 1/4W
R508 1-247-807-31 CARBON 100 5% 1/4W
R509 1-249-433-11 CARBON 22K 5% 1/4W
! R510 1-215-444-00 METAL 9.1K 1% 1/4W
! R511 1-249-381-11 CARBON 1 5% 1/4W
R512 1-249-389-11 CARBON 4.7 5% 1/4W
R513 1-215-888-00 METAL OXIDE 220 5% 2W
R514 1-215-387-00 METAL 39 1% 1/4W
R515 1-249-417-11 CARBON 1K 5% 1/4W
R516 1-214-844-81 METAL 150 1% 1/2W
R517 1-216-394-00 METAL OXIDE 2.7 5% 3W
R518 1-216-394-00 METAL OXIDE 2.7 5% 3W
R519 1-247-903-00 CARBON 1M 5% 1/4W
! R520 1-249-405-11 CARBON 100 5% 1/4W
R521 1-249-417-11 CARBON 1K 5% 1/4W
R522 1-249-401-11 CARBON 47 5% 1/4W
R523 1-215-463-00 METAL 56K 1% 1/4W
R524 1-215-463-00 METAL 56K 1% 1/4W
R525 1-249-417-11 CARBON 1K 5% 1/4W
R526 1-260-095-11 CARBON 470 5% 1/2W
! R527 1-249-429-11 CARBON 10K 5% 1/4W
R528 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R529 1-260-095-11 CARBON 470 5% 1/2W
! R530 1-216-474-11 METAL OXIDE 82 5% 3W
! R531 1-216-474-11 METAL OXIDE 82 5% 3W
! R532 1-249-385-11 CARBON 2.2 5% 1/4W
R533 1-249-417-11 CARBON 1K 5% 1/4W
R534 1-249-405-11 CARBON 100 5% 1/4W
R535 1-215-463-00 METAL 56K 1% 1/4W
R536 1-249-417-11 CARBON 1K 5% 1/4W
R537 1-215-463-00 METAL 56K 1% 1/4W
R538 1-219-746-11 CARBON 1K 5% 1/2W
R539 1-215-445-00 METAL 10K 1% 1/4W
! R540 1-215-476-00 METAL 200K 1% 1/4W
! R541 1-215-421-00 METAL 1K 1% 1/4W
! R542 1-215-421-00 METAL 1K 1% 1/4W
! R543 1-249-389-11 CARBON 4.7 5% 1/4W
! R544 1-247-889-00 CARBON 270K 5% 1/4W
! R545 1-216-691-11 METAL CHIP 47K 0.50% 1/10W
! R546 1-215-457-00 METAL 33K 1% 1/4W
! R547 1-215-477-00 METAL 220K 1% 1/4W
! R548 1-215-423-00 METAL 1.2K 1% 1/4W
! R549 1-215-464-00 METAL 62K 1% 1/4W
! R550 1-215-423-00 METAL 1.2K 1% 1/4W
R551 1-216-687-11 METAL CHIP 33K 0.50% 1/10W
! R552 1-215-463-00 METAL 56K 1% 1/4W
R553 1-216-698-11 METAL CHIP 91K 0.50% 1/10W
R554 1-218-756-11 METAL CHIP 150K 0.50% 1/10W
R556 1-216-691-11 METAL CHIP 47K 0.50% 1/10W
R557 1-216-079-00 RES-CHIP 18K 5% 1/10W
R558 1-216-675-91 METAL CHIP 10K 0.50% 1/10W
R559 1-215-431-00 METAL 2.7K 1% 1/4W
R560 1-216-679-11 METAL CHIP 15K 0.50% 1/10W
! R561 1-216-474-11 METAL OXIDE 82 5% 3W
R562 1-215-451-00 METAL 18K 1% 1/4W
R563 1-249-383-11 CARBON 1.5 5% 1/4W
! R564 1-216-687-11 METAL CHIP 33K 0.50% 1/10W
R565 1-215-481-00 METAL 330K 1% 1/4W
R566 1-215-859-00 METAL OXIDE 22 5% 1W
! R567 1-216-073-91 RES-CHIP 10K 5% 1/10W
! R568 1-249-437-11 CARBON 47K 5% 1/4W
R569 1-216-643-11 METAL CHIP 470 0.50% 1/10W
R570 1-219-749-91 CARBON 10K 5% 1/2W
R571 1-216-069-00 RES-CHIP 6.8K 5% 1/10W
R572 1-260-288-11 CARBON 0.47 5% 1/2W
! R574 1-249-421-11 CARBON 2.2K 5% 1/4W
R575 1-260-316-51 CARBON 100 5% 1/2W
