2. Peel the conductive tape [1] on the display cable connector.
3. Remove the adhesive strip that secures the display cable connector [2].
4. Lift the latch and disconnect the display cable from the connector on the display panel [3, 4].
NOTE: Do not pull and release the Stretch (SR) Tapes from the display panel. There is no need to separate the
brackets from the display panel.
94 Disassembly and reassembly
