Replacing the status-light board
WARNING: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in Before working inside your computer. After working inside your computer, follow the instructions in After working inside
your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1 Place the status-light board in the slot on the palm-rest assembly and snap it into place.
2 Slide the status-light board cable under the speaker cable.
3 Connect the status-light board cable to the system board.
Post-requisites
1 Replace the battery.
2 Replace the base cover.
28
Replacing the status-light board 47
