Replacing the keyboard
WARNING: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in Before working inside your computer. After working inside your computer, follow the instructions in After working inside
your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1 Place the keyboard cable on the back of the keyboard.
2 Align the keyboard cable along the folding line and fold the keyboard cable.
3 Place the keyboard on the palm-rest assembly and align the screw holes on the keyboard with the screw holes on the palm-rest
assembly.
4 Replace the six screws (M1.2x1.5) that secure the keyboard to the palm-rest assembly.
34
58 Replacing the keyboard
