Removing the touchpad
WARNING: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in Before working inside your computer. After working inside your computer, follow the instructions in After working inside
your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
1 Remove the base cover.
2 Remove the battery.
3 Remove the speakers.
4 Remove the status-light board.
Procedure
1 Open the latch and disconnect the touchpad cable from the system board.
2 Peel o the two adhesive tapes that secure the touchpad to the keyboard bracket.
3 Remove the three screws (M2x2.5) that secure the touchpad bracket to the palm-rest assembly.
4 Lift the touchpad bracket o the palm-rest assembly.
5 Remove the four screws (M2x2.5) securing the touchpad to the palm rest assembly.
6 Slide and lift the touchpad from the slot on the palm-rest assembly.
29
48 Removing the touchpad
