Dell P992 - D Board Removal

P992 (E) 1-5
1-5. D BOARD REMOVAL
2
A board
(C block)
1
Anode cap
(Refer to 1-8)
3
Two screws
(+BVTT 4 x 8)
7
Two screws
(+BVTT 3 x 8)
Pig tail cover
14
D board
13
PWB bracket
4
Video block assembly
6
Cable with connector
8
Rear plate assembly
Screw (+BVTT 3 x 8)
11
Seven screws
(+BVTP 3 x 10)
12
9
Extension bar
CN315
CN313
CN304
GND
CN600
CN601
CN1103
CN1602
Connector (2P)
CN501
CN701
GND
GND
GND
CN
10
5
