Dell P992 - Timing Specification

P992 (E) 6
TIMING SPECIFICATION
MODE AT PRODUCTION MODE 1 MODE 2 MODE 3
RESOLUTION 640 X 480 1280 X 1024 1600 X 1200
CLOCK 25.175 MHz 135.000 MHz 229.500 MHz
— HORIZONTAL —
H-FREQ
31.469 kHz 79.976 kHz 106.250 kHz
usec usec usec
H. TOTAL 31.778 12.504 9.412
H. BLK 6.356 3.022 2.440
H. FP 0.636 0.119 0.279
H. SYNC 3.813 1.067 0.837
H. BP 1.907 1.837 1.325
H. ACTIV 25.422 9.481 6.972
— VERTICAL —
V. FREQ (HZ)
59.940 Hz 75.025 Hz 85.000 Hz
lines lines lines
V. TOTAL 525 1066 1250
V. BLK 45 42 50
V. FP 10 1 1
V. SYNC 23 3
V. BP 33 38 46
V. ACTIV 480 1024 1200
— SYNC —
INT(G) NO NO NO
EXT (H/V) /POLARITY YES N/N YES P/P YES P/P
EXT (CS) /POLARITY NO NO NO
INT/NON INT NON INT NON INT NON INT
2001.6.15 VER.
