1
B
A
C
Two screws
(+BVTP 4 x 16)
6
Slide the EMI shield in the direction
of arrow C and remove four claws.
7
EMI shield
4
Two screws
(+BVTT 3 x 8)
5
Six screws
(+BVTT 4 x 8)
2
Two claws
3
Push the upper side of the cabinet
inthe direction of arrow A, disconnect claws
then remove the cabinet
lifting it up in the direction of arrow B.
Bezel assembly
Bezel assembly
EMI shield
Cabinet
Cabinet
Push in the tip of a screwdriver
about 10mm to unlock the claw.
To Next Page
