34
The following information must be obtained from the network administrator before configuring
the device:
• The IP address to be assigned to the VLAN 1 interface through which the device is to be
managed (by default, every port is a member of the VLAN 1 in Managed Mode).
• The IP subnet mask for the network
• The default gateway (next hop router) IP address for configuring the default route.
The system supports Embedded Web Server (EWS), which serves HTML pages through which the
device can be monitored and configured. The switch supports the following browsers: Microsoft IE
V6.x and higher, and Mozilla. The system internally configures the device according to Web-based
input (including menu selections, mouse clicks, etc.).
The device is delivered in Unmanaged Mode. The device must be changed to Managed Mode
before it can be configured. To change to Managed Mode, the device must be fully operational in
Unmanaged Mode (Managed Mode LED has stopped blinking and is off). Once the Managed
Mode LED has stopped blinking, press the Managed Mode button. The switch reboots and the
Managed Mode LED blinks for approximately 90 seconds and stays lit. When the Managed Mode
LED stays lit, the switch is ready to be configured. The default IP address is 192.168.2.1, the
default User Name is 'admin', and the default password is left blank.
The following login screen is displayed when the device is first connected:
Figure 4-1. Login Screen
1
Enter
admin
in the
User Name
field
.
2
Leave the
Password
field blank (for first time Managed Mode access).
3
Click
OK
.
To change User name and Password, see Local User Database.
On first deployment of the device (after the device is initially connected with the default settings),
it is advisable to configure the device with new configuration parameters.
To configure the switch with new system-specific parameters, perform the following steps:
1
Open the
IP Addressing
window in the EWS.
