• Ports — Port that can be added to a Multicast service.
•
LAGs — LAGs that can be added to a Multicast service.
The following table contains the IGMP port and LAG members management settings:
Adding Bridge Multicast Addresses
1 Open the Bridge Multicast Group page.
2 Click Add .
The
Add Bridge Multicast Group page opens:
Figure 7-28. Add Bridge Multicast Group
3 Define the VLAN ID and New Bridge Multicast Address fields.
D The port/LAG has joined the Multicast group
dynamically in the Current Row.
F The port/LAG is excluded from this Multicast
group.
S Attaches the port to the Multicast group as
static member in the Static Row.
The port/LAG has joined the Multicast group
statically in the Current Row.
Blank The port is not attached to a Multicast group.
