182 Jumpers and Connectors
14 SATA_A SATA A connector
15 CTRL_PNL Control panel connector
16 BATTERY System battery
17 ISCSI_KEY NIC hardware key
18 INT_STORAGE SAS Integrated storage controller card connector
19 PWRD_EN
NVRAM_CLR
Password enable jumper
NVRAM clear jumper
Table 6-2. System Board Jumpers and Connectors (continued)
Item Connector Description
