DellPowerVault™TL4000/TL2000FailoverGuide


10|Page 12/31/09 version 2.0
SingleSASDriveFailoverConfiguration
(onehostwithtwoHBAs,andOneSASdrive)
MainPath
Failover Path

Figure6:ReferenceConfiguration6
FailoverReferenceConfiguration7:
OnehostwithtwoFibreChannelHBAs,oneFibreChannelswitchandoneDellPowerVault™
withaSingleFibreChanneldrive
Inthisconfiguration,failoveroccursonlyifoneoftheHBAsfails.Thisconfigur ationonlysupportsdata
pathfailoverasthereisnoseconddrivetofailoverthecontrolpath.Thephysicalconnectionofthis
configurationisshowninFigure7.



Alwaysrefertowww.dell.com\supportforlatestdocumentationandupdates

