Dell Precision 3431 Small Form Factor Service Manual

Cable cover for Dell Precision 3431 Small Form
Factor
The cable cover for a Dell Precision 3431 Small Form Factor helps protect ports and cables connected to the system.
Follow these steps to install the cable cover on the system chassis.
NOTE:
Images shown below are for representation only and may vary depending on the system's configuration.
1. Slide the latch away from the chassis to unlock the cable cover.
2. Pull the tab on the cable release latch and lift the latch away from the cable cover.
3.
Lift the tab [1], to release and pull the cable tie from the slot on the cable release latch [2].
4. Align the cable release latch on the system chassis slot [1]. Tighten the single screw to secure the cable release latch to the system
chassis [2].
D
Cable cover for Dell Precision 3431 Small Form Factor 125
