Inside Your Computer
DellPrecision™WorkStation340ServiceManual

Small Desktop Computer


Mini-Tower Computer

NOTE: User service access points are color- coded green.
1
removable media drive
9
AC power connector
2
hard drive
10
padlock ring
3
cover release buttons (2)
11
back-panel connectors
4
speaker
12
microprocessor/blower assembly
5
chassis intrusion switch
13
memory modules
6
power supply
14
system board
7
expansion-card cage
15
floppy drive
8
PCI expansion-card slots (2)


