About your monitor │ 13
7 DisplayPort 1.2 Connect to your computer using a DisplayPort
cable (purchased separately).
8 Audio line out port Connect to an external speaker or a sub-woofer
(purchased separately).*
9 USB 3.0 upstream
port
Connect the USB cable from this port to your
computer to enable the USB ports on your
monitor.
10 USB 3.0 downstream
ports
Connect your USB peripherals such as storage
devices and printers.
NOTE: To use this port, you must
connect the USB upstream cable
(shipped with your monitor) between
the monitor and the computer.
11 USB 3.0 downstream
with BC 1.2 charging
USB 3.0 downstream port with charging
capability. Connect to charge your USB device.
NOTE: To use this port, you must
connect the USB upstream cable
(shipped with your monitor) between
the monitor and the computer.
12 Built-in left speaker Provides audio output.
*Audio line out port does not support headphones.
