.1.3.6.1.4.1.6027.3.26.1.4.8.1.2.3 = STRING: "mfs:398"
.1.3.6.1.4.1.6027.3.26.1.4.8.1.2.4 = STRING: "/dev/ld0h"
.1.3.6.1.4.1.6027.3.26.1.4.8.1.2.5 = STRING: "tmpfs"
.1.3.6.1.4.1.6027.3.26.1.4.8.1.3.1 = INTEGER: 4624894
.1.3.6.1.4.1.6027.3.26.1.4.8.1.3.2 = INTEGER: 59503
.1.3.6.1.4.1.6027.3.26.1.4.8.1.3.3 = INTEGER: 148847
.1.3.6.1.4.1.6027.3.26.1.4.8.1.3.4 = INTEGER: 2008708
.1.3.6.1.4.1.6027.3.26.1.4.8.1.3.5 = INTEGER: 51200
.1.3.6.1.4.1.6027.3.26.1.4.8.1.4.1 = INTEGER: 521636
.1.3.6.1.4.1.6027.3.26.1.4.8.1.4.2 = INTEGER: 1
.1.3.6.1.4.1.6027.3.26.1.4.8.1.4.3 = INTEGER: 2545
.1.3.6.1.4.1.6027.3.26.1.4.8.1.4.4 = INTEGER: 400528
.1.3.6.1.4.1.6027.3.26.1.4.8.1.4.5 = INTEGER: 60
.1.3.6.1.4.1.6027.3.26.1.4.8.1.5.1 = INTEGER: 3872014
.1.3.6.1.4.1.6027.3.26.1.4.8.1.5.2 = INTEGER: 56527
.1.3.6.1.4.1.6027.3.26.1.4.8.1.5.3 = INTEGER: 138860
.1.3.6.1.4.1.6027.3.26.1.4.8.1.5.4 = INTEGER: 1608180
.1.3.6.1.4.1.6027.3.26.1.4.8.1.5.5 = INTEGER: 51140
.1.3.6.1.4.1.6027.3.26.1.4.8.1.6.1 = STRING: "/usr/pkg"
.1.3.6.1.4.1.6027.3.26.1.4.8.1.6.2 = STRING: "/tmpimg"
.1.3.6.1.4.1.6027.3.26.1.4.8.1.6.3 = STRING: "/f10/ConfD/db"
.1.3.6.1.4.1.6027.3.26.1.4.8.1.6.4 = STRING: "/f10/flash"
.1.3.6.1.4.1.6027.3.26.1.4.8.1.6.5 = STRING: "/f10/phonehome"
MIB Support to Display Egress Queue Statistics
Dell Networking OS provides MIB objects to display the information of the packets transmitted or dropped per unicast or multicast egress
queue. The following table lists the related MIB objects:
Table 98. MIB Objects to display egress queue statistics
MIB Object OID Description
dellNetFpEgrQTxPacketsRate 1.3.6.1.4.1.6027.3.27.1.20.1.6 Rate of Packets transmitted per Unicast/
Multicast Egress queue.
dellNetFpEgrQTxBytesRate 1.3.6.1.4.1.6027.3.27.1.20.1.7 Rate of Bytes transmitted per Unicast/
Multicast Egress queue.
dellNetFpEgrQDroppedPacketsRate 1.3.6.1.4.1.6027.3.27.1.20.1.8 Rate of Packets dropped per Unicast/
Multicast Egress queue.
dellNetFpEgrQDroppedBytesRate 1.3.6.1.4.1.6027.3.27.1.20.1.9 Rate of Bytes dropped per Unicast/
Multicast Egress queue.
MIB Support to Display Egress Queue Statistics
Dell Networking OS provides MIB objects to display the information of the ECMP group count information. The following table lists the
related MIB objects:
Table 99. MIB Objects to display ECMP Group Count
MIB Object OID Description
dellNetInetCidrECMPGrpMax 1.3.6.1.4.1.6027.3.9.1.6 Total CAM for ECMP group.
dellNetInetCidrECMPGrpUsed 1.3.6.1.4.1.6027.3.9.1.7 Used CAM for ECMP group.
dellNetInetCidrECMPGrpAvl 1.3.6.1.4.1.6027.3.9.1.8 Available CAM for ECMP group.
880 Simple Network Management Protocol (SNMP)
