14 │ About your monitor
Monitor specifications
Model SE2423DS SE2723DS
Screen type Active matrix-TFT LCD
Panel type In-Plane Switching Technology
Aspect ratio 16:9
Viewable image
Diagonal 604.50 mm (23.80 in.) 684.70 mm (26.96 in.)
Horizontal, Active Area 526.85 mm (20.74 in.) 596.74 mm (23.49 in.)
Vertical, Active Area 296.35 mm (11.67 in.) 335.66 mm (13.21 in.)
Area 156132.00 mm
2
(242.01
in.
2
)
200301.75 mm
2
(310.47
in.
2
)
Maximum resolution
and refresh rate
2560 x 1440 at 75 Hz
Pixel pitch 0.2058 mm x 0.2058 mm 0.2331 mm x 0.2331 mm
Pixel per inch (PPI) 123 109
Viewing angle
Horizontal
Vertical
178° (typical)
178° (typical)
Luminance output 300 cd/m² (typical) 350 cd/m² (typical)
Contrast ratio 1000 to 1 (typical)
Faceplate coating Anti-glare treatment of the front polarizer (3H) hard
coating
Backlight LED edgelight system
Color depth 16.70 million colors
Color gamut sRGB 99% (typical)
