NOTE: For models shipped with a speaker cable featuring an eight-pin connector, to disconnect the speaker cable from
the system board, pry up the bottom side of the cable connector's head first and then pull it away from the connector.
3. Lift the speakers along with its cable from the palm-rest and keyboard assembly.
Installing the speakers
Prerequisites
If you are replacing a component, remove the existing component before performing the installation process.
About this task
The following images indicate the location of the speakers and provide a visual representation of the installation procedure.
