Installing the power switch
1 Insert the power switch into the slot from the front of the computer and press it until it clicks into place.
2 Align the cable with the pins on the connector and connect the cable.
3 Close the front panel door.
4 Install the:
a bezel
b cover
5 Follow the procedure in After working inside your computer.
Coin cell battery
Removing the coin cell battery
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a cover
b bezel
3 Open the front panel door.
4 To remove the coin cell battery:
a Press the release latch until the coin cell battery pops out.
b Remove the coin cell battery from the connector on the system board.
18
Removing and installing components
