Table 1. Screw list (continued)
Component Secured to Screw type Quantity Screw image
Processor fan and heat-
sink assembly
Chassis Captive screw
M3
4
Front I/O bracket Chassis #6-32 1
System board Chassis #6-32 9
Major components of XPS 8950
The following image shows the major components of XPS 8950.
NOTE: Depending on the configuration ordered, some components may or may not be present in your computer.
Removing and installing components 11
