Door assembly
● Grip the door (as indicated in
figure 18) and refit it in reverse
order of removing procedure.
Removing the oven door
Please operate as follows:
● Open the door completely.
● The swivel retainers of the rh and
lh hinges (fig. 18a) are hooked
onto the metal bar above them
(fig. 18b).
● Lift the oven door slightly. The
noch on the bottom of the hinge
will disengage (fig. 18c).
● Now pull the oven door forwards
off the appliance. Release both
hinge sections from the slots (fig.
18d).
Fig. 18
Fig. 18a
Fig. 18b
Fig. 18c
Fig. 18d
