Owner´s Manual DEA600 Radio
14 | P a g e
Media Audio Control Softkeys
The system present the next control softkeys as part of the Media sources
interface.
•
Play/Pause
•
Next
•
Previous
•
Repeat
•
Shuffle
•
Search
•
Views
The softkeys are placed at the bottom of the Audio App screen.
In the case the CD media, USB or the Bluetooth media source is selected,
the user interface is illustrated on the
Figure 16Figure 16Figure 16.
The system senses a long press of the next softkey for 2 seconds in order to
activate the fast forward function. The system senses a long press of the
previous softkey for 2 seconds in order to activate the fast reverse function.
The system displays the track time bar located under the album artwork of
the file that is being played.
Figure 17: Track Time Bar
In the case the USB media source is active the system indicates the type of
audio file displayed.
The Audio file is identified by one of the following options.
•
Song
•
Album
Search
If the Search softkey is selected the search screen is displayed with the next
elements:
•
White Box
•
Keyboard
The Keyboard works as the user-system interface to acquire the
alpha/numeric search. The white box displays the acquired information. The
system continue playing audio while performing the search. The
Figure
18Figure 18Figure 18
illustrates the search screen.
Con formato: Fuente:
(Predeterminado) Arial, 9 pto, Negrita
Con formato: Fuente:
(Predeterminado) Arial, 9 pto, Negrita,
Sin subrayado, Color de fuente:
Automático
Con formato: Fuente:
(Predeterminado) Arial, 9 pto, Negrita
Con formato: Fuente:
(Predeterminado) Arial, 9 pto, Negrita,
Sin subrayado, Color de fuente:
Automático
