Delphi DEA610 User Manual

Owner´s Manual DEA600 Radio
23 | P a g e
Figure 31: Audio App Tuner Sources.
The system displays up to 12 presets memories in a tab divider manner at
the bottom of the screen interface. Each preset work as softkey button
selector. The presets that do not have a frequency assigned display only the
number of the grid.
In order to save a station in to a memory:
• Tune the desired station.
• Press and hold one of the 6 presets
• When the selected station is displayed on the preset, the station
has been saved in the selected preset.
The system displays the current tuned frequency along with the
corresponding radio Band.
The systems display a specific screen interface for the Sirius XM source.
AM/FM
The system presents the next control softkeys as part of the AM/FM radio
source interface.
• Next
• Previous
• Scan
• Strong Station list
• Update List
The AM/FM radio sources screens follow the distribution and styling as the
Figure 31Figure 31Figure 31 illustrates.
WX
The WX band is for the Governmental weather radio services frequencies;
the radio can tune 7 weather channels.
The system presents the next control softkeys as part of the WX radio
source interface.
• Next
• Previous
• SCAN
The system presents 7 presets for this application. To save stations in to
preset follow the AM-FM instructions.
The WX radio source screen is illustrated in Figure 32Figure 32Figure 32 .
Con formato: Fuente:
(Predeterminado) Arial, 9 pto, Negrita
Con formato: Fuente:
(Predeterminado) Arial, 9 pto, Negrita,
Sin subrayado, Color de fuente:
Automático
Con formato: Fuente:
(Predeterminado) Arial, 9 pto, Negrita
Con formato: Fuente:
(Predeterminado) Arial, 9 pto, Negrita,
Sin subrayado, Color de fuente:
Automático
