Owner´s Manual DEA600 Radio
45 | P a g e
The User Defined Virtual Gauges Priorities does
not modify the Default
Virtual Gauges Priorities.
Gauge Population
Automatic arrangement is used to identify available gauges.
The population of the gauges for the Automatic arrangement is depending
on the priority preset selected.
The priority preset is configurable through the Settings menu of the Virtual
gauges app.
Automatic Population
The Virtual Gauges are populated by adding gauges if the relative vehicle
information is available. The Virtual Gauges app adds available gauges
following the priority established.
The actual Virtual Gauges page from the Virtual Gauges app page is
highlighted, allowing the user to differentiate it from the disabled pages and
from the active pages that are not selected as the actual page.
The Standard Priority list of gauges have a higher priority than the Optional
Gauges, even if a given gauge from the Optional gauges shares a priority
level with a gauge from the Standard Priority gauges.
If not Available information for a specific Gauge is received from the vehicle
information bus is received the related Gauge is hidden. Some virtual
gauges show a specific icon in the case of a not available gauge.
The Virtual Gauges app pages for gauges population are disabled if there
are no gauges in the page. The disabled Virtual Gauges app pages are
displayed in an opaque manner.
The active Virtual Gauges app pages are displayed in clear way which
allows the user to differentiate between the actual page and disabled pages.
As the optional virtual gauges become available, they starts to be
accommodated from the last active gauge displayed filling the available slots
in all the pages in an incremental order and following the preset priority.
The Virtual Gauges app does not allow the user to select the disabled gauge
pages until they become available.
Each time a Virtual Gauges app page is filled with gauges, the Virtual
Gauges app activate the subsequent page, in an incremental order, to
continue placing the active virtual gauges.
Priority presets
Priority Preset 1
Gauge
Priority
Engine Oil Temperature Page One
Main Trans Oil Temperature
Manifold Pressure (Boost)
Fuel Economy Page One
Percent Torque Page One
Percent Horsepower NA
Idle Time NA
Idle Fuel NA
Fuel Usage Rate NA
Drive Axle #1 (front) Oil Temperature
Drive Axle #2 (rear) Oil Temperature
Drive Axle #3 (center) Oil Temperature
Air Filter Restriction Pressure 6
Fuel Filter Restriction/Fuel Pressure Gauge
7
Air Suspension Pressure 1 5
Tractor Brake Application N/A – In Cluster
Pusher Axle #1 Pressure 8
PTO Hour Meter 9
Priority Preset 2
Gauge
Priority
Manifold Pressure (Boost) Page One
DPF Status Page One
Fuel Economy Page One
Percent Torque Page One
