Error! No text of specified style in document. DNS-24, DNT-T103, & DNT-T221 Application Guide
Page 4 of 35
Document Edition 3.1
Use the NEXT and PREVIOUS buttons to navigate through the menu options. Once you have navigated to the
desired item you wish to display or change, use the arrow buttons to make any necessary changes. Once the
changes are made or you wish to move on, press N
EXT or PREVIOUS.
3. C
ONFIGURATION MENU OPTIONS
The Configuration Menu is a list of items which you can navigate through and make changes to as you need for
setup purposes. The Configuration Menu items are as follows:
Menu Item Description
CFg
Displayed momentarily to indicate you have successfully entered the Configuration
Menu.
[Application] The Control Application (AV12). You may choose from any of the following
applications:
•
None This disables all control strategies and allows the outputs and control
icons to be controlled remotely from another device.
•
VAV This enables the VAV control strategy and allows you to configure the
outputs for your VAV application.
•
VVT This enables the VVT control strategy and allows you to configure the
outputs for your VVT application.
•
HPU This enables the HPU control strategy and allows you to configure the
outputs for your Heat Pump Unit application.
•
FCU This enables the FCU control strategy and allows you to configure the
outputs for your Fan Coil Unit application.
•
Unt This is no longer an option. Configure control for a Unit Heater using
the FCU application.
•
rAd This enables the Radiation control strategy and allows you to configure
the outputs for your Radiant Heating application.
•
HuM This enables the Humidity control strategy and allows you to configure
the outputs for your Humidity application.
OP1
Output 1 Configuration. This includes the output function and type (what it will
control and how) and other setup parameters as required (such as delays or limits).
OP2
Output 2 Configuration. This includes the output function and type (what it will
control and how) and other setup parameters as required (such as delays or limits).
OP3
Output 3 Configuration. This includes the output function and type (what it will
control and how) and other setup parameters as required (such as delays or limits).
[More] Additional parameters to set, which are dependent on the Application and Output
Configuration, may include:
•
Run Actuator Runtime in seconds (AV24)
•
AFF Air Flow Factor for VAV only (AV25)
•
Min Minimum Air Flow for VAV and Damper Minimum for VVT (AV26)
•
MAM Maximum Air Flow for VAV and Damper Maximum for VVT (AV27)
DEG
The Temperature Units Setting (degrees C or F).
[Settings] Additional control settings, which are particularly useful when an Application is
selected for local control, typically include:
•
Set Day Setpoint (AV6) • HI Max. Day Setpoint (AV8)
•
DIF Day Differential (AV9) • Pb CO Proportional Band (AV19)
• LO Min. Day Setpoint (AV7) • rr CO Reset Rate (AV20)
To Next Page
