Chapter 12 Application Examples|ASDA-A&A+ Series
12-34 Revision April 2009
2. B/A = 0/1 or B/A = 0/3
Position
Z pulse
CWL / ORGP
SPEED
3. B/A = 1/2
Position
Z pulse
ORGP
SPEED
4. B/A = 1/3
Position
Z pulse
ORG
P
SPEED
