Chapter 3 Connections and Wiring|ASDA-A&A+ Series
3-36 Revision April 2009
CN2 Terminal Signal Identification
ASDA-A Series
PIN No. Signal Name
Terminal
Identification
Military
Connector
Quick
Connector
Description
2 /Z phase input /Z G 6 Encoder /Z phase output
4 /A phase input /A B 2 Encoder /A phase output
5 A phase input A A 1 Encoder A phase output
7 B phase input B C 3 Encoder B phase output
9 /B phase input /B D 4 Encoder /B phase output
10 Z phase input Z F 5 Encoder Z phase output
14, 16 Encoder power +5V S 7 Encoder 5V power
13, 15 Encoder power GND R 8 Grounding
Shielding Shielding L 9 Shielding
ASDA-A+ Series
PIN No. Signal Name
Terminal
Identification
Military
Connector
Quick
Connector
Description
4 Line driver /SD /SD B 2
Encoder line driver /SD
signal output
5 Line driver SD SD A 1
Encoder line driver SD
signal output
14,16 Encoder power +5V S 7 Encoder 5V power
13,15 Encoder power GND R 8 Grounding
Shielding Shielding L 9 Shielding
