Chapter 1 Unpacking Check and Model Explanation|ASDA-A&A+ Series
Revision April 2009 1-7
1.3 Servo Drive and Servo Motor Combinations
The table below shows the possible combination of Delta ASDA-A and ASDA-A+ series servo drives and
ASMT and ECMA series servo motors. The boxes (î
) in the model names are for optional configurations.
(Please refer to Section 1.2 for model explanation)
ASDA-A Series Servo Drive
Servo drive Servo motor
100W ASD-A0121Lî
ASMT01L250î
î
200W ASD-A0221Lî
ASMT02L250î
î
400W ASD-A0421Lî
ASMT04L250î
î
750W ASD-A0721Lî
ASMT07L250î
î
1000W ASD-A1021Lî
ASMT10L250î
î
2000W ASD-A2023Lî
ASMT20L250î
î
Low
inertia
3000W ASD-A3023Lî
ASMT30L250î
î
1000W ASD-A1021Mî
ASMT10M250î
î
1500W ASD-A1521Mî
ASMT15M250î
î
2000W ASD-A2023Mî
ASMT20M250î
î
Medium
inertia
3000W ASD-A3023Mî
ASMT30M250î
î
