Chapter 7 Servo Parameters|ASDA-A&A+ Series
Revision April 2009 7-25
P0 - 13 MAP4 Block Data Read / Write Register 4 Communication Addr.: 000DH
Default: 111H Related Section: N/A
Applicable Control Mode: ALL
Unit: N/A
Range: 100H ~ 417H
Settings: See P0-09 for explanation.
P0 - 14 MAP5 Block Data Read / Write Register 5 Communication Addr.: 000EH
Default: 112H Related Section: N/A
Applicable Control Mode: ALL
Unit: N/A
Range: 100H ~ 417H
Settings: See P0-09 for explanation.
P0 - 15 MAP6 Block Data Read / Write Register 6 Communication Addr.: 000FH
Default: 225H Related Section: N/A
Applicable Control Mode: ALL
Unit: N/A
Range: 100H ~ 417H
Settings: See P0-09 for explanation.
P0 - 16 MAP7 Block Data Read / Write Register 7 Communication Addr.: 0010H
Default: 109H Related Section: N/A
Applicable Control Mode: ALL
Unit: N/A
Range: 100H ~ 417H
Settings: See P0-09 for explanation.
P0 - 17 SVSTS Servo Output Status Display Communication Addr.: 0011H
Default: N/A Related Section:
Applicable Control Mode: ALL Table 7.B
Unit: N/A
Range: N/A
Settings:
This parameter is used to display the digital output signal of the servo drive. The servo output
status display will show in hexadecimal format.
