Chapter 7 Servo Parameters|ASDA-A&A+ Series
Revision April 2009 7-47
P1 - 53
RES2 Regenerative Resistor Capacity Communication Addr.: 0135H
Default: - Related Section:
Applicable Control Mode: ALL Section 6.6.3
Unit: Watt
Range: 30 ~ 1000 (ASDA-A series)
0 ~ power of the drive (ASDA-A+ series)
Settings:
ASDA-A series
Model Default
1.5kW and below 60
above 1.5kW 120
ASDA-A+ series
Model Default
4.5kW 100
5.5kW and above 0
P1 - 54
PER Positioning Completed Width Communication Addr.: 0136H
Default: 100 Related Section: N/A
Applicable Control Mode: Pt , Pr
Unit: pulse (ASDA-A series, Pr mode of ASDA-A+ series)
1/10000 rev. (Pt mode of ASDA-A+ series)
Range: 0 ~ 10000
Settings:
In Pt mode, when the error pulse numbers is less than the setting value of parameter P1-54,
TPOS (At positioning completed signal) will be activated.
In Pr mode, when the difference in pulse number between the target position and the actual
position is less than the setting value of parameter P1-54, TPOS (At positioning completed
signal) will be activated.
P1 - 55
MSPD Maximum Speed Limit Communication Addr.: 0137H
Default: rated speed Related Section: N/A
Applicable Control Mode: ALL
Unit: r/min
Range: 0 ~ Max. speed
Settings:
This parameter is used to set maximum motor speed. The default setting is rated speed.
